Fig.134
If the rails are not yet fully inserted after removing the
drawer:
u
Push rails in completely.
Inserting drawer
Fig.135
u
Slide rails in.
u
Place drawer on rails.
u
Slide in drawer to the back.
8.7 Compartment lid for EasyFresh Safe
The compartment lid ensures constant levels of humidity.
The compartment lid is directly on the drawer and can be
covered by shelves or additional drawers.
Fig. 136 Example illustration, compartment lid for EasyFresh
Safe
(1)
EasyFresh Safe (3) Shelf
(2) Compartment lid for
EasyFresh Safe
8.7.1 Reducing the air humidity in the drawer
Fig.137
u
Pull out the drawer Fig.137(1).
u
Grasp the recessed grip Fig. 137 (2) on the compartment
lid and pull the compartment lid forwards at the same
time.
w
When the drawer is closed, there is a small gap between
the compartment lid and the drawer.
8.7.2 Increasing the air humidity in the drawer
Fig.138
u
Pull out the drawer Fig.138(1).
u
Grasp the recessed grip Fig. 138 (2) on the compartment
lid and push the compartment lid backwards at the same
time.
w
When the drawer is closed, the compartment lid seals
with the drawer.
8.8 Glass shelves
You can remove the glass shelves under the drawers for
cleaning.
You can remove the glass shelves under the drawers to use
VarioSpace.
8.8.1 Removing / inserting the glass shelf
Make sure that the following requirements are fulfilled:
q
Glass shelf under the drawer: The drawer has been
removed. (see8.6 Drawers)
Removing glass shelf
Fig. 139 Example illustration of glass shelf
u
Lift glass shelf at the front. Fig. 139(1)
u
Take out glass shelf to the front. Fig. 139(2)
Inserting glass shelf
Fig. 140 Example illustration of glass shelf
u
Position glass shelf at an angle behind the stoppers. (see
Fig. 140)
u
Lower glass shelf.
Features
28 * Depending on model and options
