8.1.2 Inserting the door rack
Fig. 88 Example illustration
u
Slide in the door rack.
u
Press the door rack down.
8.1.3 Removing the bottle holder
Fig.89
u
Slide the bottle holder to the side as far as the recess.
u
Remove the bottle holder forwards.
8.1.4 Inserting the bottle holder
Fig.90
u
Insert the bottle holder in the recess.
u
Push the bottle holder to the desired position to the side.
8.2 Shelves
8.2.1 Adjusting/removing the shelves
The shelves are prevented from being pulled out acciden‐
tally by pull out stops.
Fig. 91
u
Lift the shelf and pull forward.
w
Line up the side runner.
u
Adjust the height of the shelf: Lift or lower it to the
desired height and slide it in.
-or-
Fig.92
u
Remove the shelf completely: Pull it out to the front.
u
Easier removal: Set the shelf at an angle.
u
Insert the shelf again: Slide it in all the way.
w
The pull-out stoppers point downwards.
w
The pull-out stoppers are behind the front support.
8.3 Dividing shelf
8.3.1 Using the dividing shelf
The shelves are prevented from being pulled out acciden‐
tally by pull out stops.
Fig. 93
u
Push the dividing shelf underneath as shown.
Fig. 94
Adjusting the height:
u
Pull the glass panels out Fig. 94 (1) from the front, one at
a time.
u
Release the support rails and click in at the height you
want.
u
Slide in the glass panels one at a time.
w
Flat pull-out stoppers at the front, right behind the
support rails.
w
High pull-out stoppers at the back.
Using both shelves:
u
Hold the glass panel with one hand and pull it to the
front.
w
The glass panel Fig. 94(1) and trim strip are at the front.
w
The stops Fig. 94(3) point down.
8.4 Space for baking tray
There is space for a baking tray Fig.1(6) above the drawers.
Features
22 * Depending on model and options
