9.3.1 Removing the compartment lid
Ensure that the following requirements are met:
q
The shelf directly above the drawer has been removed.
(see8.2 Shelves)
q
The drawer directly below the compartment lid has been
removed. (see8.6 Drawers)
Fig. 154
u
Push the compartment lid backwards.
u
Lift the compartment lid forwards.
u
Remove the compartment lid forwards and upwards at an
angle.
9.3.2 Inserting the compartment lid
Fig. 155
If the THIS SIDE UP lettering is at the top:
u
Insert the rear retaining parts into the relevant rear open‐
ings.
u
Push the compartment lid backwards.
u
Lower the compartment lid forwards and engage the
front retaining parts into the openings.
u
Move the compartment lid into the required position.
9.4 Defrosting the appliance
WARNING
Improper defrosting of the appliance!*
Injuries and damage.
u
Do not use mechanical equipment or other methods to
speed up the defrosting process other than those recom‐
mended by the manufacturer.
u
Do not use electrical heating or steam-cleaning appli‐
ances, naked flames or defroster sprays to defrost.
u
Do not use sharp objects to remove ice.
9.4.1 Defrosting the fridge compartment
Defrosting is performed automatically. The water from the
thawing process drains through the outlet and evaporates.
Water drops or a thin layer of frost or ice can form on the
back wall; this is a completely normal part of the applian‐
ce’s function. This must not be removed.
A layer of frost or ice can from briefly due to the energy-
optimised control of the device.*
A layer of frost or ice can from briefly due to the energy-
optimised control of the device.*
u
Clean the drain opening at regular intervals.
(see 9.5Cleaning the appliance)
9.4.2 Defrosting the freezer compartment with
NoFrost*
Defrosting is performed automatically with the NoFrost
system. The moisture is deposited on the evaporator, is peri‐
odically defrosted and evaporates.
The appliance does not have to be defrosted.
9.4.3 Defrosting the freezer compartment
manually*
A layer of frost or ice forms after prolonged use.
The following factors promote the formation of frost or ice:
- The appliance is opened frequently.
- Hot food is put in.
One day before defrosting:
u
Activate SuperFrost. (see 7.2Appliance functions)
w
Frozen goods have a “residual coldness”.
u
Switch the appliance off.
u
Pull the mains plug out of the socket or switch the fuse
off.
u
Wrap the frozen produce in newspaper or blankets and
store in a cool place.
u
Place a pan of hot water (not
boiling) on the middle shelf.
w
This speeds up the defrosting process.
u
Leave the appliance door open during defrosting.
u
Remove loosened pieces of ice.
u
Make sure that there is no melted ice water in the
cabinet.
u
Soak up the melted ice water with a sponge or cloth
several times as necessary.
u
Clean the appliance. (see 9.5Cleaning the appliance)
9.5 Cleaning the appliance
9.5.1 Ready
WARNING
Danger of electric shock!
u
Remove the refrigerator connector or interrupt the power
supply.
WARNING
Risk of fire
u
Do not damage the refrigeration circuit.
u
Empty the appliance.
u
Remove mains connector.
-or-
u
Activate CleaningMode. (see CleaningMode*) *
Maintenance
32 * Depending on model and options
