Fig. 126
► Pull VarioSafe forwards Fig. 126 (1) until the recesses in
the side of the VarioSafe are at the level of the support
rib in the fridge section. Fig. 126(2)
Fig.127
► Set VarioSafe in refrigerator compartment at an angle.
Fig.127(1)
► Take VarioSafe out to the front. Fig.127(2)
▷ VarioSafe is removed.
8.4.5 Disassembling the VarioSafe
You can disassemble the VarioSafe into its individual parts if
you want to clean the VarioSafe or if you need to install or
remove parts.
Fig.128
► Remove VarioSafe as a whole. (see 8.4.4 Removing the
VarioSafe )
► Disassemble VarioSafe according to the illustration.
8.5 Space for baking tray
There is space for a baking tray Fig.1(8) above the drawers.
Fig.129
Ensure that the following conditions are met:
❑
Max. baking tray dimensions are adhered to
(see 10.1 Technical specifications) .
❑
Baking tray is cooled to room temperature.
❑
The lowest door rack is set at least one position higher.
With the door open to 90°:
► Slide the baking tray onto the lower side runners.
8.6 Drawers
You can remove the drawers for cleaning.
You can remove the drawers to use VarioSpace.
The way to remove/insert the drawers varies depending
on the pull-out system. Your appliance can contain various
pull-out systems.
Note
The energy consumption increases and the cooling power
goes down if ventilation is not sufficient.
► Leave the bottom drawer in the appliance!
► Always leave the fan air vents clear on the back wall!
8.6.1 Drawer on appliance base or glass shelf
The drawer runs directly on the appliance base or on a glass
shelf. There are no rails.
When you remove the drawers, you can use the glass
shelves below them as storage shelves.
Removing drawer
Fig.130
► Remove drawer as shown in the illustration.
Inserting drawer
Fig.131
► Insert drawer as shown in the illustration.
Features
26 * Depending on model and options
