8.1.2 Inserting the door rack
Fig. 107 Example illustration
► Slide in the door rack.
► Press the door rack down.
8.1.3 Removing the bottle holder
Fig. 108
► Slide the bottle holder to the side as far as the recess.
► Remove the bottle holder forwards.
8.1.4 Inserting the bottle holder
Fig. 109
► Insert the bottle holder in the recess.
► Push the bottle holder to the desired position to the side.
8.2 Shelves
8.2.1 Adjusting/removing the shelves
The shelves are prevented from being pulled out acciden‐
tally by pull out stops.
Fig. 110
► Lift the shelf and pull forward.
▷ Line up the side runner.
► Adjust the height of the shelf: Lift or lower it to the
desired height and slide it in.
-or-
Fig.111
► Remove the shelf completely: Pull it out to the front.
► Easier removal: Set the shelf at an angle.
► Insert the shelf again: Slide it in all the way.
▷ The pull-out stoppers point downwards.
▷ The pull-out stoppers are behind the front support.
You can also remove the shelf above the EasyFresh
compartments.
Fig.112
Removing the shelf:
If the IceMaker (see 8.9 IceMaker*) has been removed:*
► Lift the shelf at the front and back.*
► Lift the shelf at the front and back.*
► Pull it out towards you.
Do not store any goods on the compartment cover below!
Inserting the shelf:
► Place the shelf at an angle, sloping down towards the
back.
▷ The pull-out stoppers point downwards.
► Slide the shelf into place.
8.2.2 Dismantling the shelves
The shelves can be dismantled for cleaning.
Fig.113
► Dismantling the shelf.
8.3 Dividing shelf*
8.3.1 Using the dividing shelf
The shelves are prevented from being pulled out acciden‐
tally by pull out stops.
Features
* Depending on model and options 23
