u
Pull it out towards you.
Do not store any goods on the compartment cover below!
Inserting the shelf:
u
Place the shelf at an angle, sloping down towards the
back.
w
The pull-out stoppers point downwards.
u
Slide the shelf into place.
8.2.2 Dismantling the shelves
The shelves can be dismantled for cleaning.
Fig. 110
u
Dismantling the shelf.
8.3 Dividing shelf*
8.3.1 Using the dividing shelf
The shelves are prevented from being pulled out acciden‐
tally by pull out stops.
Fig.111
u
Push the dividing shelf underneath as shown.
Fig.112
Adjusting the height:
u
Pull the glass panels out Fig.112(1) from the front, one at
a time.
u
Release the support rails and click in at the height you
want.
u
Slide in the glass panels one at a time.
w
Flat pull-out stoppers at the front, right behind the
support rails.
w
High pull-out stoppers at the back.
Using both shelves:
u
Hold the glass panel with one hand and pull it to the
front.
w
The glass panel Fig.112(1) and trim strip are at the front.
w
The stops Fig.112(3) point down.
8.4 VarioSafe *
The VarioSafe offers space in the refrigerator compartment
for small groceries, packages, tubes and jars, for example.
Fig.113
(1)
VarioSafe drawer (3) Recesses on the left and
right side panel
(2) Side panels with ribs
for VarioSafe drawer
(4) Stop edge
8.4.1 Inserting the VarioSafe
Fig. 114
u
Insert the VarioSafe into the fridge section at an angle
Fig. 114 (1) until the recesses in the side Fig. 114 (2) of the
VarioSafe are at the level of the support rib in the fridge
section.
Fig. 115
u
Set VarioSafe straight. Fig. 115(1)
Features
24 * Depending on model and options
