w
Ice cubes fall from the ice cube tray into the ice cube
drawer Fig.70(5).
If all the ice cubes do not come out of the ice cube tray:
u
Turn the rotary knob clockwise several times to the stop.
8.3 VarioSpace
Fig.73
You can remove drawers and glass panels from your appli‐
ance. This provides more room for large food items such as
poultry, joints of meat, large game, and tall baked products.
You can then freeze these items whole for later preparation.
u
Note the weight limits on the drawers and glass panels
(see 10.1 Technical specifications) .
8.4 Freezer pack*
Freezer packs prevent the temperature rising too quickly
should there be a power cut.
The freezer packs are in the drawer.
You can store the freezer packs in the freezer tray.*
8.4.1 Using the freezer pack
Fig. 74
When the freezer packs are fully frozen:
u
Place on the frozen goods in the top, front part of the
freezer.
9 Maintenance
9.1 Disassembling / assembling pull-
out systems
9.1.1 Notes on disassembly
You can disassemble some of the pull-out systems for
cleaning. Your appliance can contain a variety of pull-out
systems.
The following pull-out systems can be disassembled or
cannot be disassembled:
Pull-out system
can be disassembled/
cannot be disassembled
Top tiltable drawer* cannot be disassembled*
Drawer guided on
container rib
can be disassembled
(see 9.1.2 Drawer on moulded rib)
Bottom drawer cannot be disassembled
9.1.2 Drawer on moulded rib
Disassembling pull-out system
Make sure the following prerequisites are met:
q
Drawer has been removed. (see 8.1.2 Drawer on moulded
rib)
Fig. 75 Attachment on the right moulded rib
u
Grab attachment at the back from below.
u
Pull off attachment at the back sideways. Fig.75(1)
u
Pull off attachment at the front sideways. Fig.75(2)
Installing pull-out system
Fig. 76 Attachment on the right moulded rib
u
Position attachment on moulded rib at the front.
Fig. 76(1)
u
Press on attachment at the back. Fig. 76(2)
9.2 Defrosting the appliance
9.2.1 Defrosting with NoFrost
Defrosting is performed automatically with the NoFrost
system. The moisture is deposited on the evaporator, is peri‐
odically defrosted and evaporates.
The appliance does not have to be defrosted.
Note
Water droplets may collect on the bottom of the appliance.
When you take the appliance out of operation:
u
Place a towel in front of the appliance to catch any water
droplets that escape. (see11Shutting down)
Maintenance
* Depending on model and options 19
