18
freezer ComparTmenT
Removing the Freezer Compartment
Containers
The containers of both freezer drawers can be removed.
• Unlatch the container on the left and right corners by
pulling upwards (1) - Figure 18.
• Slide the container backwards (2) - Figure 18.
Figure 18
• Tilt the container at an angle and remove - Figure 19.
Install the container in the reverse order.
Figure 19
Figure 17
Freezer Compartment Description
The ice maker is located in the upper drawer on the right
side.
The ice cubes fall out of the ice maker into the drawer.
The upper drawer is divided by a partition wall for stor-
ing ice cubes in the right part of the drawer (Figure 17).
If you need more ice cube storage space, pull up the
partition wall and refit on the adjacent rail (Figure 17).
If you need the whole upper drawer for freezing and
storing food, turn off the ice maker (see chapter “Turning
the Ice Maker On and Off”).
The bottom drawer is intended for freezing and storing
food. Ice cubes can also be stored in this drawer.
Space for ice cubes
