Fig. 145 Components of the EasyTwist-Ice
(1) EasyTwist-Ice body
with ice cube tray
(3) Cover
(2) Water tank (4) Ice cube drawer
NOTICE
Risk of damage due to improper dismantling!
Equipment breaking, jumping and cracking. If you dismantle
the EasyTwist-Ice body further, you may damage the rotary
knob or other parts of the EasyTwist-Ice body.
► Only dismantle the EasyTwist-Ice into the components
shown. (see Fig. 145)
► Clean the EasyTwist-Ice body Fig. 145(1) as a whole.
Cleaning the EasyTwist-Ice
Make sure that the following requirements are fulfilled:
❑
The EasyTwist-Ice is dismantled. (see Dismantling the
EasyTwist-Ice)
► Clean the ice cube drawer, water tank, cover and Easy‐
Twist-Ice body with warm water and a little detergent.
► Dry all cleaned components thoroughly with a dry cloth.
▷ The EasyTwist-Ice is clean.
Installing the EasyTwist-Ice
Fig. 146
► Installing the EasyTwist-Ice body cover: Place the cover
on the front. Fig. 146(1)
► Lower the cover at the rear. Fig. 146(2)
▷ The cover locks into both tabs Fig. 146(3) audibly.
Fig. 147
► Installing the EasyTwist-Ice body: Push the axes for the
EasyTwist-Ice body into the guides Fig. 147(4).
► Press the EasyTwist-Ice body Fig. 147 (5) down at the
back.
▷ The EasyTwist-Ice body locks in audibly.
Fig. 148
► Insert the ice cube drawer Fig. 148(6).
WARNING
Risk of poisoning due to contaminated water!
► Only fill the water tank with potable water.
► Fill the water tank with water.
► Insert the water tank.
► Insert the drawer. (see 8.5 Drawers)
If you are using unfiltered water:
► Dispose of ice cubes that were produced 24 hours after
initial ice cube production.
-or-
If you are using filtered water:
► Dispose of ice cubes that were produced 48 hours after
initial ice cube production.
9.5.7 After cleaning
► Wipe the appliance and the components dry.
► Connect and switch on the appliance.
► Activate SuperFrost (see 7.2Appliance functions) .
The temperature is cold enough:
► Place the food inside.
► Repeat cleaning regularly.
Maintenance
32 * Depending on model and options
