w
Side recess to shelf position.
u
Reposition the shelf: Lift up or lower to the desired
height and insert.
-or-
Fig.84
u
Take out the shelf completely: Pull out to the front.
u
Easier removal: Set the shelf at an angle.
u
Reinsert the shelf: Push it in to its stop limit.
w
Pull-out stoppers are pointing down.
w
Pull-out stoppers are behind the front shelf.
You can also remove the shelf above the EasyFresh
compartments.
Fig.85
To remove shelf
u
Lift the shelf at the front and back.
u
Remove from the front.
Do not place any goods on the drawer cover below!
Slide the shelf in:
u
Place the shelf at an angle, with the back tilted
downwards.
w
Pull-out stoppers are pointing down.
u
Slide the shelf into place.
8.2.2 Dismantling shelves
The shelves can be dismantled for cleaning.
Fig.86
u
Disassemble the shelf.
8.3 Split shelf*
8.3.1 Using the split shelf
CAUTION
Broken shelves!
Danger of cuts.
u
Only remove storage shelves when there is nothing
on them
Extension stops secure the shelves against being acci‐
dentally pulled out
Fig. 87
u
Push the split shelf underneath as in the illustration
Fig.88
Adjusting heights:
u
Pull the glass panels out Fig. 88 (1) from the front,
one at a time.
u
Pull the support rails out of their retainers and snap
into place at the height you want them.
u
Slide in the glass panels one at a time.
w
Flat pull-out stoppers at the front, right behind the
support rail.
w
Taller pull-out stoppers at the back.
Using both shelves:
u
Hold the bottom glass panel with one hand and pull
it to the front.
w
The glass panel Fig. 88 (1) with the trim strip is at the
front.
w
The stops Fig.88(3) point downward.
8.4 VarioSafe *
The VarioSafe offers space in the refrigerator compart‐
ment for small groceries, packages, tubes and jars, for
example.
Equipment
* Depending on model and options 25
