LG XD64W handleiding
Handleiding
Je bekijkt pagina 13 van 56
13
EN
Removing the Top Cover
If the height of the opening is below 850 mm,
follow these instructions.
1
Remove the 2 screws on the back.
2
Pull the top cover backwards after removing
the two screws and then lift it up to remove
it.
3
Remove the locating pins on the top by
using a Phillips screw driver.
NOTE
• When the appliance is correctly leveled, there
should be no slant, stickiness or rubbing
sound when the door is opened.
Levelling the Appliance
Levelling the appliance prevents unnecessary
leakage and poor washing. Place the appliance
on a solid, level floor. Do not install the
appliance on an elevated surface.
If the appliance is not properly level, adjust all
levelling feet as necessary.
Turn them clockwise to raise and counter-
clockwise to lower until the appliance no longer
wobbles, both front-to-back and side-to-side and
corner-to-corner.
Levelling feet
Levelling feet
NOTE
• The appliance is not level if there is a rubbing
sound or stickiness when the door is opened.
