4
Before Installation
• Do not use the product for any purpose other than installing the TV on a
wall.
• Avoid product damage and safety accidents caused by careless installing or
use of improper or unauthorized wall mount.
• Follow the instructions in the installation manual for a convenient
installation of the wall mount.
• Immediately discontinue installation and contact the service center if you
cannot fully understand the installation process.
Use a professional installer if any installation issues remain after the
inquiry.
• Installation of this product on a concrete wall or wood stud is
recommended. Installation on walls made of other types of plasterboard,
plywood, brick, etc., is not recommended since there is a greater chance
the product will fall.
• Install the product only on a vertical wall.
Do not install on a tilted wall that exceeds building standards or on the
heavily titled wall or ceiling.
LG is not responsible for problems caused by improper installation of the
product, e.g., heavily tilted walls and ceilings.
• Check the enclosed accessories before installation. We are not responsible
for any lost or damaged accessories after the inner packaging is opened.
• When an infant or small child swallows the enclosed accessories, various
safety accidents such as choking may occur. Keep the enclosed accessories
out of the reach of infants and children.
• When tightening screws, tighten until fully snug. Avoid using excessive
force when tightening the screws. Doing so may damage the wall and
product or reduce the rigidity or performance of the product.
• Avoid installing a TV that exceeds the specied tensile load, and do not
allow any external force to be applied to the product.
• Avoid accidents by using work tools with care during installation.
Tools for Installation
- “+” shaped screwdriver (manual or electric)
- 8mm spanner
- level
- drill
- Ø8mm drill bit for concrete or Ø4mm drill bit for steel
How to install
How to install
• The appearance of tools may dier from the enclosed images.
• Always consult a professional when installing a wall mount.
1. Wearing gloves
2. Fastening Anchors and Screws
• Check that the material and thickness of the wall and nishing material
comply with the installation manual. Before beginning the mounting
process, you must be sure the wall is able to support the weight of the TV.
• Should use the enclosed anchors and screws on crack free concrete walls.
• If the wall is not made of concrete, the wall mount must be installed on a
rigid support. Never install the product on a plasterboard or wall made of
paper or medium-density berboard (MDF). In this case, make sure that
the wall material can withstand the weight of the TV, and x the anchor
screws to the retaining wall (concrete) or wooden support behind the
nishing material. Since the anchors provided with this product may not be
suitable for your wall material, be sure to check with a professional before
attempting installation.
• Other unspecied walls must be capable of supporting pullout loads of
over 70 kgf (154 lbf) (686 N) and shear loads of over 100 kgf (220.5 lbf )
(980 N) per fastener.
• Use an Ø 8 mm drill bit for concrete and a hammer (impact) drill or Ø 4 mm
drill bit for wood stud to drill holes.
