5
Securing TV to the Wall
1 Insert and tighten the eye-bolts, or TV brackets and bolts on the back of
the TV.
• If there are bolts inserted at the eye-bolts position, remove the bolts
first.
2 Mount the wall brackets with the bolts to the wall. Match the location of
the wall bracket and the eye-bolts on the rear of the TV.
3 Connect the eye-bolts and wall brackets tightly with a sturdy rope. Make
sure to keep the rope horizontal with the flat surface.
• Use a platform or cabinet that is strong and large enough to support the
TV securely.
• Brackets, bolts and ropes are not provided. You can obtain additional
accessories from your local dealer.
Stand (Separate Purchase)
This model has a built-in slim wall mount bracket. If you want to install a
stand, you can purchase it separately through LG TV sales store and LG online
brand shop. (Wall mount included model only)
(Depending on model)
Stand Model
SA-G5SN55 OLED55G5*
SA-G5SN65 OLED65G5*
ST-G4WR8377 OLED77/83G5*
SQ-G2DT97 OLED97G5*
Mounting to the Wall
Attach an optional wall mount bracket at the rear of the TV carefully and
install the wall mount bracket on a solid wall perpendicular to the floor.
When you attach the TV to other building materials, please contact qualified
personnel. LG recommends that wall mounting be performed by a qualified
professional installer. We recommend the use of LG’s wall mount bracket.
LG’s wall mount bracket is easy to move with cables connected. When you
do not use LG’s wall mount bracket, please use a wall mount bracket where
the device is adequately secured to the wall with enough space to allow
connectivity to external devices. It is advised to connect all the cables before
installing fixed wall mounts.
• Ask a professional installer appointed by the store for installation of the
product.
Installation by someone other than a professional installer is extremely
dangerous and may result in personal injury.
• Do not install the product in an unstable site that cannot withstand its
weight.
If the installation site lacks sufficient rigidity, the product may fall and
cause personal injury.
• Remove the stand before installing the TV on a wall mount by
performing the stand attachment in reverse.
• For more information of screws and wall mount bracket, refer to manual
included in the separately purchased wall mount.
• If you intend to mount the product to a wall, attach VESA standard
mounting interface (optional parts) to the back of the product. When
you install the set to use the wall mounting bracket (optional parts), fix
it carefully so as not to drop.
• When mounting a TV on the wall, make sure not to install the TV by
hanging the power and signal cables on the back of the TV.
• Do not install this product on a wall if it could be exposed to oil or oil
mist. This may damage the product and cause it to fall.
• When installing the Full Contact Wall Mount, the TV may not be
contacted firmly against the wall due to some wall conditions.
