9INSTALLATION
ENGLISH
The mounting plate b is located in the upper
packing material.
NOTE
• Vent grille appearance varies by model.
Make sure you have enough space and support.
• Mount the oven against a flat, vertical wall, so it
is supported by the wall. The wall should be
constructed of a minimum of 2" x 4" wood
studding and 3/8" thick drywall or plaster/lath.
• Attach the two lag screws supporting the oven to
a vertical, 2" x 4" wall stud.
• Do not mount the microwave oven to an island
or peninsula cabinet.
• Be sure the upper cabinet and rear wall
structures can support 150 lbs., plus the weight
of any items you place inside the oven or upper
cabinet.
• Locate the oven away from areas with strong
drafts, such as windows, doors, and strong
heating vents.
• Be sure you have enough space (minimum
vertical and horizontal clearance).
a Maximum 13": cabinet depth
b Minimum 30": cabinet opening width
c Minimum 30": clearance from bottom of
cabinet to cooking surface or countertop
before installation. (Use templates included
with installation instructions.)
d Grounded Outlet (inside upper cabinet)
e Power Supply Cord Hole
WARNING
• If you do not mount the oven as instructed, you
risk personal injury and/or property damage.
• If your range has cooktop controls in the front,
unplug the range before covering the cooktop to
prevent risk of fire and damage if the knobs are
accidentally activated while installing the OTR.
• The product is heavy. Use at least 2 people when
lifting or installing the appliance to avoid injury
or product damage.
CAUTION
• Before you begin installing the oven, place a
piece of the carton or other heavy material (a
blanket) over the countertop or cooktop to
protect it. Do not use a plastic cover. Failure to
protect these surfaces could result in property
damage.
Parts
Included Parts
NOTE
• Depending on your ventilation requirements,
you may not use all of these parts.
a Power cord clamp bushing (1ea): for the cord
hole in a metal upper cabinet
b 1/4" x 2" lag screw (2ea): for wall stud holes
