19
EN
Right Door
If the door is too low, lift the right door up and
insert use a pair of long nose pliers to insert
ring sheets until both doors are level.
Height difference
Fridge door
Freezer door
Adjusting the Freezer Door
If the door of the appliance is not level, adjust
the difference in the height of appliance door
using the following method.
NOTE
• Because the hinge pin may fall out, do not
adjust the height of the appliance door more
than 5 cm.
*Reference
Spanner
Keeper nut
Adjustment hinge pin
1
Loosen the keeper nut by rotating it
counterclockwise using a 19 mm spanner.
To loosen the nut
2
Adjust the difference in the height of the
appliance door by rotating the adjustment
hinge pin clockwise or counterclockwise
with an 8 mm spanner.
Up
Down
3
After adjusting the difference in the height
of the appliance door, fasten the keeper nut
by rotating it clockwise.
To tighten the nut
If it is impossible to adjust the height of the
appliance door through the above method, level
the door according to the following guide.
