15
EN
Dimensions and Clearances
• Too small of a distance from adjacent items
may result in the degradation of freezing
capability and increased electricity costs. Allow
over 50 mm of clearance from each adjacent
wall when installing the appliance.
A
C
E
H
FG
B
D
Type Depth A Depth B
A 912 mm 912 mm
B 1797 mm 1797 mm
C 924 mm 759 mm
D 20 mm 20 mm
E 898 mm 733 mm
F 904 mm 739 mm
G 996 mm 996 mm
H 1637 mm 1637 mm
NOTE
• You can determine what type of appliance it is
by looking at the label inside the fridge
compartment.
Ambient Temperature
• The appliance is designed to operate within a
limited range of ambient temperatures,
depending on the climate zone. Do not use
the appliance at a temperature exceeding the
limit.
• The internal temperature could be affected by
the location of the appliance, the ambient
temperature, the frequency of door opening
and so on.
• The climate class can be found on the rating
label.
Climate Class
Ambient Temperature
Range ºC
SN (Extended
Temperate)
+10 - +32
N (Temperate) +16 - +32
ST (Subtropical) +16 - +38
T (Tropical) +16 - +43 / +10 - +43*
*Australia, India, Kenya
NOTE
• The appliances rated from SN to T are
intended to be used at an ambient
temperature between 10 ºC and 43 ºC.
