10 PRODUCT OVERVIEW
i Ice Bin
If a large amount of ice is needed, transfer the ice in the in-door ice bin to an ice storage bin in the
freezer.
j Automatic Icemaker B (Freezer)
†
Produces ice automatically.
k Adjustable Refrigerator Shelf
The refrigerator shelves are adjustable to meet individual storage needs.
l Folding Shelf
†
Store taller items, such as gallon containers or bottles, by pushing the front half of the shelf
underneath the back half of the shelf.
m Instaview
†
Knock twice on the glass to turn the LED light inside the InstaView on or off.
n Door-in-Door Compartment
†
Stores commonly used food items such as beverages and snacks.
o Control Panel
Sets the refrigerator and freezer temperatures or other functions.
p Glide'N'Serve
Stores food items at a different temperature than the regular refrigerator area.
q Pullout Drawer
Provides extra storage within the freezer compartment.
r Durabase and Durabase Divider
Provides storage for large frozen food items.
Product Specifications
The appearance and specifications listed in this manual may vary due to constant product improvements.
Electrical requirements: 115 V, 60 Hz
Min. / Max. water pressure: 20 - 120 psi (138 - 827 kPa)
Model Description Net weight
LF24Z6530*
LF24Z6330*
Counter-depth, French Door Refrigerator, Bottom Freezer 261 lb (118 kg)
LF25Z6211* Counter-depth, French Door Refrigerator, Bottom Freezer 236 lb (107 kg)
LY24Z6231* Counter-depth, French Door Refrigerator, Bottom Freezer 254 lb (115kg)
