13INSTALLATION
ENGLISH
NOTE
• a 30" (76.2 cm) minimum clearance between the top of the cooking surface and the bottom of an
unprotected wood or metal cabinet; or 24" (60.9 cm) minimum when bottom of wood or metal cabinet is
protected by not less than 1/4" (6.4 cm) flame retardant millboard covered with not less than no. 28 MSG
sheet steel, 0.015" (0.381 mm) stainless steel, 0.024" (0.610 mm) aluminum or 0.020" (0.508 mm) copper.
• g 15" (38.1 cm) minimum between countertop and adjacent cabinet bottom.
• Important – Save for the use of the local electrical inspector.
• For installation in Canada, a free-standing range is not to be installed closer than 15/32" (12 mm) from
any adjacent surface.
Clearances
b Minimum clearance to left/right wall
5" (12.7 cm)
c Maximum depth for cabinets above countertops
13" (33.0 cm)
d Front edge of the range side panel forward from cabinet
2 1/4" (6.3 cm)
e To cabinets below cooktop and at the range back
0"
f Minimum opening in overhead cabinets
30" (76.2 cm)
g Minimum distance from countertop to overhead cabinets at side
18" (45.7 cm)
h Height of countertop
36" (91.3 cm)
a Acceptable Electrical Outlet Area b Normal Countertop Depth
c Countertop Height d Cabinet
e Wall f Center
g Cabinet opening
= 30" (76.2 cm) For U.S.A
= 30" (76.2 cm) ~ 31" (78.7 cm) For CANADA
