G
O
1
2
N
•
•
Slot
Insert
5 Align the tabs on the diffuser with slots in the
outer slide section. Insert the diffuser into the
opening in the vent panel.
Screw
6 Insert the screw in the hole in the diffuser to
prevent the diffuser from sliding out of the
vent opening.
NOTE
• For a tighter seal, use "no residue" duct tape (not provided) to seal any gaps around the installed
panel assembly, around the diffuser, and between the sashes.
• For best results, keep the vent hose as short and straight as possible. However, shape the diffuser
end of the vent hose into an inverted U shape just inside the window to allow any rain or
condensation to drain out the window.
Best positioning Inverted U shape
INSTALLATION
16
