13
EN
4
Rotate hinge lever counterclockwise. Lift the
top hinge free of the hinge lever latch.
Hinge Lever
Latch
5
Lift the door from the middle hinge pin and
remove the door.
CAUTION
• When removing the upper hinge, be sure to
support the door as it will fall forwards. It is
recommended that two or more people carry
out the door removal and refitting.
• When lifting the hinge free of the latch, be
careful that the door does not fall forward.
• Place the door on a non-scratching surface
with the inner side facing up.
NOTE
• When moving the left fridge door, be careful
not to damage the water tubes. The doors
should be laid down on a blanket in a safe
area once they have been removed.
• If the water tube end is damaged, it should be
trimmed to ensure it does not leak when
refitted.
Not straight Damaged Stretched
• While pressing the collet toward the tube
connector, gently insert the water tube until
only one line is visible. Pull on the water tube
to make sure that the tube is tightly fastened.
Collet
Water tube
Insert line
<Correct>
<Incorrect>
