10 INSTALLATION
Dimensions and Clearances
• Check the dimensions of the appliance and the installation path to ensure there is sufficient room to
move the refrigerator through doors or narrow openings.
• If an opening is too narrow to fit the refrigerator through, remove the refrigerator doors. See Removing/
Assembling the Doors and Drawers in this manual.
• The installation location chosen for the refrigerator should allow space behind the unit for connections
and airflow and space in front to open the doors and drawers.
• Too small of a distance from adjacent items may result in lowered freezing capability and increased
electricity consumption charges. Allow at least 2 inches (50 mm) between the back of the refrigerator
and the wall.
• Remember to allow enough room in front of the refrigerator to fully open the doors and drawers.
Removing/Assembling
Handles
These instructions are for models which ship with
the handles assembled. For models shipped with
the handles disassembled, follow the instructions
included in the handle package.
• Tools Needed
- Units shipped with disassembled handles:
3/32" and 1/4" Allen wrenches only
- Units shipped with assembled handles:
3/32", 1/8" and 1/4" Allen wrenches
When moving the refrigerator through a narrow
opening, removing the doors is preferred. If you
must remove the handles, be very careful not to
scratch the doors.
The appearance of the handles may vary from
what is shown.
CAUTION
• When assembling or disassembling the
refrigerator handles, grasp the handle firmly to
avoid dropping it.
- Dimension/Clearance
LS27T3230*
LL27T3530*
LS27H3230*
A Depth without Handle 33 11/16” (856 mm) 33 11/16” (856 mm)
B Width 35 7/8" (912 mm) 35 7/8" (912 mm)
C Height to Top of Case 69" (1752 mm) 69" (1752 mm)
D Height to Top of Hinge 70 1/2" (1790 mm) 70 1/2" (1790 mm)
E Back Clearance 2" (50 mm) 2" (50 mm)
F Depth without Door 32 1/8" (817 mm) 32 1/8" (817 mm)
G Depth with Handle 36 1/8” (917 mm) 36 1/4” (921 mm)
H Depth (Total with Door Open 90°) 51 1/8” (1299 mm) 51 1/8” (1299 mm)
