FILL TUBE INSTALLATION
BEFORE YOU BEGIN
Read each step thoroughly before proceeding.
TOOLS YOU WILL NEED
CAUTION: Unplug the refrigerator power cord from the outlet.
INSTALLATION INSTRUCTIONS
Flat blade and
Phillips screwdrivers
1 . REMOVE THE ICEMAKER FILL TUBE COVER
R
(Apply only for model; LRTLS2403*)
Locate the marks on the back of the cabinet
where the fill tube will be installed. Place the
5 screws on the marks and tap them with the
screwdriver to make a small hole. Fasten the
fill tube using the band and the Phillips
screws.
emove and discard the icemaker fill tube
opening cover located on the upper right
side of the refrigerator; insert the icemaker
fill tube all the way into the opening until
it stops.
3. S
FILL TUBE INSTALLATION
ECURE THE FILL TUBE
2. SECURE THE FILL TUBE
4
WrongOK
.
A
B
A
2
12
11
5
12
B
2
25
12
Position the tube connector as shown. Insert the
tube from the water valve (white) in the left
opening . Then remove the clip from around
the right opening , insert the icemaker fill tube
(black), and reinsert to secure the tube
Insert tubes until only one guideline is showing.
Tug gently to make sure the tube is secure.
