11
HOW TO REMOVE AND INSTALL REFRIGERATOR DOOR
1. Removing Refrigerator Doors
NOTE: Handle, top hinge and hinge cover appearance may vary from illustrations on this page.
WARNING
• Disconnect electrical supply to the refrigerator before installing. Failure to do so could result in death or serious
injury.
• Do not put hands or feet or metal sticks into the air vents, base grille, or bottom of the refrigerator. You may be
injured or receive an electrical shock.
• Be careful when you work with the hinge, base grille, and stopper. You may be injured.
X Left Door
• Open the door. Remove the top hinge cover screw (1 ).
• Use a flat blade screwdriver to lift the tabs on the front underside of the cover(2). Lift up the cover.
• Disconnect all wire harness (3).
• Remove the grounding screw(4).
• Rotate hinge lever (5) counterclockwise. Lift the top hinge (6) free of the hinge lever latch (7).
• Place the door on a non-scratching surface with the inside up.
X Right Door
• Open the door. Remove the top hinge cover screw (8).
• Use a flat blade screwdriver to lift the tabs on the front underside of the cover (9). Lift up the cover.
• Rotate hinge lever (10) clockwise. Lift the top hinge (11) free of the hinge lever latch (12).
• Place the door on a non-scratching surface with the inside up.
CAUTION: When lifting the hinge free of the latch, be careful that the door does not fall forward.
•Liftthedoorfromthemiddlehingepinandremovethedoor.
•Placethedoor,insidefacingup,onanonscratchingsurface.
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
REFRIGERATOR INSTALLATION REFRIGERATOR INSTALLATION
