17INSTALLATION
ENGLISH
1 Make sure the surface of the washer is clean
and dry. Remove paper backing from the tape
on one of the stacking kit side brackets.
2 Fit the side bracket to the side of the washer
top as shown. Firmly press the adhesive area
of the bracket to the washer surface. Secure
the side bracket to the washer with a screw on
the back side of the bracket. Repeat steps 1
and 2 to attach the other side bracket.
3 Place the appliance on top of the washer,
fitting the dryer feet into the side brackets as
illustrated. Avoid finger injuries; do not allow
fingers to be pinched between the washer
and the appliance. Slowly slide the appliance
toward the back of the washer until the side
bracket stoppers catch the dryer feet.
4 Insert the front rail between the bottom of
the appliance and the top of the washer. Push
the front rail toward the back of the washer
until it comes in contact with the side rail
stoppers. Install the two remaining screws to
secure the front rail to the side rails.
Stacking the Appliance on Mini-
Washer or Pedestal
WARNING
• The weight of the appliance makes the support
assembly and stacking process too risky for one
person. Two or more people are required when
installing the supports to stack the appliance on
a mini washer or pedestal.
Use the provided supports when stacking the
dryer on a mini-washer or pedestal.
1 Tilt the dryer from the left and right sides of
the dryer. Fit the supports to the sides of the
dryer bottom as shown.
CAUTION
• Do not lay the dryer on its side or it could
malfunction.
2 Secure the support to the dryer with a screw.
Repeat steps 1 and 2 to attach the other
supports, two on each side.
3 Stack the dryer following the instructions in
the manual included in the mini washer or
pedestal.
Connecting Electric Dryers
WARNING
• To reduce the risk of fire or explosion, electric
shock, property damage, injury to persons, or
