18 INSTALLATION
8 Reverse the l upper hinge assembly and n
hinge filler.
• Carefully lift
l the upper hinge assembly-
inner top lock rod (on the left) out of the
outer door frame. Rotate the
lupper hinge
assembly - inner top lock rod 180 degrees
and install it on the upper right side of the
outer door. You will need to press firmly to
install the hinge assembly.
• Now rotate the
n hinge filler 180 degrees
and install it on the upper left side of the
door.
9 Reinstall the g top lock rod using 2 screws
removed in 6 step.
10 Reverse the i lower hinge bracket and k
hinge assembly.
1) Remove the screw from the
i lower
hinge bracket (on the right) and lift the
hinge bracket out. Set it aside. Remove
the two screws from the
k lower hinge
assembly on the bottom left and lift the
hinge assembly out.
2) Rotate the k lower hinge assembly 180
degrees and install it on the right side
using the two screws removed in a
previous step.
3) Flip over the
i lower hinge bracket and
release the tabs on the back locking the
e hinge filler to the hinge bracket.
4) Rotate the hinge 180 degrees and snap it
back onto the front of the hinge bracket
facing in the opposite direction.
