17INSTALLATION
ENGLISH
8 Reverse the g upper hinge assembly and k
hinge filler.
• Carefully lift
g the upper hinge assembly-
inner top lock rod (on the left) out of the
outer door frame. Rotate the g upper
hinge assembly - inner top lock rod 180
degrees and install it on the upper right
side of the outer door. You will need to
press firmly to install the hinge assembly.
• Now rotate the
k hinge filler 180 degrees
and install it on the upper left side of the
door.
9 Reinstall the i top lock rod holder using 2
screws removed in step 6.
10 Reverse the h lower hinge bracket and j
hinge assembly.
1) Remove the screw from the
h lower
hinge bracket (on the right) and lift the
hinge bracket out. Set it aside. Remove
the two screws from the
j lower hinge
assembly on the bottom left and lift the
hinge assembly out.
2) Rotate the j lower hinge assembly 180
degrees and install it on the right side
using the two screws removed in a
previous step.
3) Flip over the h lower hinge bracket and
release the tabs on the back locking the
e hinge filler to the hinge bracket.
4) Rotate the hinge filler 180 degrees and
snap it back onto the front of the hinge
bracket facing in the opposite direction.
5) Mount the lower hinge bracket and the
filler on the left side of the door with the
screw removed in a previous step.
