11INSTALLATION
ENGLISH
Unpacking the Cooktop
1 Unpack and visually inspect the cooktop for
any damage or missing components.
2 Be sure the bottle of cleaner and conditioner
packed in the literature bag is left where the
user can find it easily. It is important that the
ceramic-glass cooktop be pretreated before
use. See Care and Cleaning.
Model and Serial Number Location
The model and serial numbers are located on a
plate on the front side of the cooktop. Please
record them in this guide; you will need them for
warranty registration.
Technical Specifications
NOTE
• The maximum power of each cooking zone depends on the size and material of the cookware used.
Models CBIS3018BE
Description Induction Cooktop
Electrical
Specificatio
ns
Connection
voltage
240/208 VAC 60 Hz., 36.7 A / 34.6 A
Maximum
connected
power load
8800 W / 7179 W
Cooktop Dimensions 30 11/16" (781 mm) (W) × 4 1/8" (105 mm) (H) × 21 1/16" (534 mm) (D)
Countertop Cutout
Dimensions
Standard Installation
28 1/2" (724 mm) (W) × 5 3/4" (146 mm) (H) × 19 5/8" (498 mm) (D)
Cooking Zones
Position Size Power (Level 9 / Boost)
Front Left
8 1/2" x 7 1/4"
(216.2 mm x 185 mm)
1513/3026 W (208 V)
1850/3700 W (240 V)
Front Right
6 1/2"
(165 mm)
1145/1472 W (208 V)
1400/1800 W (240 V)
Rear Left
8 1/2" x 7 1/4"
(216.2 mm x 185 mm)
1513/3026 W (208 V)
1850/3700 W (240 V)
Flex Left
8 1/2" x 14 9/16"
(216.2 mm x 370 mm)
2699/3026 W (208 V)
3300/3700 W (240 V)
Center
11 1/8" / 7 1/16"
(283 mm / 180 mm)
Inner Burner:
1513/3026 W (208 V)
1850/3700 W (240 V)
Dual Burner:
3026/4089 W (208 V)
3700/5000 W (240 V)
