Je bekijkt pagina 41 van 438

• If you are using a proxy server, then temporarily disable it to load the web page correctly.

2 Click Settings > Fax > Fax Setup > General Fax Settings.

3 Configure the settings.

4 Apply the changes.

Setting up the fax function using etherFAX

Notes:

• The printer firmware must be updated to the latest version. For more information, see “Updating

firmware” on page 75.

• An appropriate license bundle must be installed in your printer. For more information, contact etherFAX.

• Make sure that you have registered your printer to the etherFAX portal. For more information, go to

https://www.etherfax.net/lexmark.

• The printer serial number is required on registration. To locate the serial number, see “Finding the printer

serial number” on page 10.

1 Open a web browser, and then type the printer IP address in the address field.

Notes:

• View the printer IP address on the home screen. The IP address appears as four sets of numbers

separated by periods, such as 123.123.123.123.

• If you are using a proxy server, then temporarily disable it to load the web page correctly.

2 Click Settings > Fax > Fax Setup > General Fax Settings.

Note: Fax Setup appears only if Fax Mode is set to Fax.

3 In the Fax Name field, type a unique name.

4 In the Fax Number field, enter the fax number that etherFAX provided.

5 From the Fax Transport menu, select etherFAX.

Notes:

• This menu shows up only when more than one fax transport is available.

• If the printer only has etherFAX installed, then it is automatically configured.

6 Apply the changes.

Setting up the fax function using fax server

Notes:

• This feature lets you send fax messages to a fax service provider that supports e‑mail receiving.

• This feature supports outgoing fax messages only. To support fax receive, make sure that you have a

device‑based fax, such as analog fax, etherFAX, or Fax over IP (FoIP), configured in your printer.

1 Open a web browser, and then type the printer IP address in the address field.

Set up, install, and configure 41
