Surge Protective Medical Grade Power Strips
Catalog Number
5302M-1S7
5304M-1S7
5306M-1S7
5302M-1S5
5304M-1S5
5306M-1S5
5302M-2S7
5304M-2S7
5306M-2S7
5302M-2S5
5304M-2S5
5306M-2S5
Electrical Specifications
Current
15A
(12A max
continuous load)
20A (16A max
continuous load)
Voltage
125V 125V
Frequency
60Hz 60Hz
Surge Technology
MOV MOV
Performance Data
Voltage
Protection
Rating (VPR)
L-N
600V 600V
L-G
600V 600V
N-G
500V 500V
Maximum Continuous
Operating Voltage (MCOV)
150V
Maximum Surge Current,
Per Mode (L-N)
27kA
Maximum Leakage Current
<100μA
Noise Filtering
-6dB to -29dB
(100kHz to 100MHz)
Total Joules
644J
Material Specifications
Line Cord
#14/3 SJT #12/3 SJT
Enclosure
Powder Coated Steel (18ga)*
Outlet Covers
Polypropylene
Mechanical Specifications
HG Plug Configuration
NEMA 5-15P NEMA 5-20P
HG Outlet Configuration
NEMA 5-15R NEMA 5-20R
Environmental Specifications
Operating Temperature
0°C to +40°C
Storage Temperature
-10°C to +50°C
Standards and Certifications
UL/ CSA/ NOM
ETL listed to:
UL 60601-1/ C22.2 No. 60601-1
UL 60950-1/ C22.2 No. 60950-1
UL 1363A/ C22.2 No. 21
UL 1449 3rd Ed/ C22.2 No.8
NFPA
NFPA 99 2012 ed
ANSI/IEEE
Category A
Warranty
Product Warranty
Limited Lifetime
* Chromium-free paint - is also RoHS compliant
Medical Grade Power Strips
Catalog Number
5302M-1N7
5304M-1N7
5306M-1N7
5302M-1N5
5304M-1N5
5306M-1N5
5302M-2N7
5304M-2N7
5306M-2N7
5302M-2N5
5304M-2N5
5306M-2N5
Electrical Specifications
Current
15A
(12A max
continuous load)
20A (16A max
continuous load)
Voltage
125V 125V
Frequency
60Hz 60Hz
Performance Data
Maximum Leakage Current
<100μA
Material Specifications
Line Cord
#14/3 SJT #12/3 SJT
Enclosure
Powder Coated Steel (18ga)*
Outlet Covers
Polypropylene
Mechanical Specifications
HG Plug Configuration
NEMA 5-15P NEMA 5-20P
HG Outlet Configuration
NEMA 5-15R NEMA 5-20R
Environmental Specifications
Operating Temperature
0°C to +40°C
Storage Temperature
-10°C to +50°C
Standards and Certifications
UL/ CSA/ NOM
ETL listed to:
UL 60601-1/ C22.2 No. 60601-1
UL 60950-1/ C22.2 No. 60950-1
UL 1363A/ C22.2 No. 21
NFPA
NFPA 99 2012 ed
Warranty
Product Warranty
Limited Lifetime
* Chromium-free paint - is also RoHS compliant
Specifications
Dimensions
8.93" (226.8 mm)
10.80" (274.3 mm)
10" (254 mm)
2.6" (66.0 mm)
2.6" (66.0 mm)
13.80" (350.5 mm)
13" (330.2 mm)
11.93" (303.0 mm)
2.6" (66.0 mm)
16.87" (428.5 mm)
16" (406.4 mm)
15.00" (381.0 mm)
.75" (19 mm)
.75" (19 mm)
3" (76 mm)
1" (25 mm)
1" (25 mm)
1.5"
(38 mm)
3" (76 mm)
.75" (19 mm)
3" (76 mm)
1"
(25 mm)
.75" (19 mm)
Mounting Bracket for Medical Grade Power Strips
Materials Specifications
Bracket / Retainer
Powder Coated Aluminum
Mounting Hardware
Stainless Steel
