Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement

part:

Hinges

Removable tape

Remove the EDP cable

Make sure the following FRUs (CRUs) have been removed.

“Remove the LCD module” on page 45

“Remove the hinge cover” on page 47

“Remove the LCD bezel” on page 47

“Remove the strip cover” on page 48

“Remove the LCD panel” on page 49

Step 1. Peel off the tape that secure the EDP cable and then remove the EDP cable.

Figure 38. Remove the EDP cable

Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement

part:

EDP cable

Removable tape

Remove the camera cable

Make sure the following FRUs (CRUs) have been removed.

“Remove the LCD module” on page 45

“Remove the hinge cover” on page 47

“Remove the LCD bezel” on page 47

“Remove the strip cover” on page 48

“Remove the LCD panel” on page 49

Step 1. Peel off the tape that secure the camera cable. Disconnect the camera cable from the camera

board and then peel off the camera cable from the LCD cover.

Chapter 4. Removing a FRU or CRU 51
