Handleiding

“Remove the Wi-Fi card” on page 36

“Remove the speakers” on page 36

“Remove the type-C bracket” on page 37

“Remove the touchpad cable” on page 38

“Remove the heat sink” on page 38

“Remove the fans” on page 39

“Remove the I/O board” on page 40

“Remove the system board and the I/O board cable” on page 42

“Remove the LCD module” on page 45

Go to

https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement

part:

Upper case

Disassemble the LCD unit (mylar version)

The LCD unit as a whole is not an FRU. Instead, it contains FRUs as its components. Before disassembling

the LCD unit, make sure it has been detached from the upper case.

Remove the hinge cover

Make sure the following unit has been removed.

“Remove the LCD module” on page 45

Step 1. Remove the hinge cover.

Figure 31. Remove the hinge cover

Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement

part:

Hinge cover

Remove the LCD bezel

Make sure the following FRU (CRU) has been removed.

“Remove the LCD module” on page 45

“Remove the hinge cover” on page 47

Chapter 4. Removing a FRU or CRU 47
