Figure 14. Remove the speakers

Screw specifications Number of screws

M2 x L1.8 4

Go to

https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement

part:

Speakers

Remove the type-C bracket

Make sure the following FRU (or CRU) has been removed.

“Remove the lower case” on page 32

Step 1. Disconnect the battery pack cable from the system board.

Attention: Use your fingernails to pull the connector to unplug it. Do not pull the cable.

Step 2. Remove two screws and then remove the type-C bracket.

Figure 15. Remove the type-C bracket

Screw specifications Number of screws

M2 x L4 2

Chapter 4. Removing a FRU or CRU 37
