Figure 46. Remove the LCD unit
Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement part:
LCD unit
Remove the upper case assembly
Make sure the following FRUs (or CRUs) have been removed.
“Remove the lower case” on page 28
“Remove the memory module and shielding” on page 29
“Remove the storage drive, cable and bracket (for selected models)” on page 31
“Remove the battery pack” on page 33
“Remove the solid-state drive and thermal pad” on page 35
“Remove the heat sink” on page 39
“Remove the system fan” on page 42
“Remove the Wi-Fi card” on page 45
“Remove the USB board and cable” on page 47
“Remove the coin-cell battery” on page 48
“Remove the fingerprint reader and cable (for selected models)” on page 49
“Remove the system board” on page 50
“Remove the touch pad cable” on page 53
“Remove the LCD unit” on page 54
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement part:
Upper case assembly
56
Lenovo V17 Gen 3 Hardware Maintenance Manual
