Remove the USB board and cable
Make sure the following FRUs (or CRUs) have been removed.
“Remove the lower case” on page 28
Step 1. Disconnect the battery pack cable from the system board.
Attention: Use your fingernail to pull the connector to unplug it. Do not pull the cable.
Figure 31. Disconnect the battery pack cable
Step 2. Disconnect and remove the USB board cable. Remove three screws and then remove the USB
board.
Figure 32. Remove the USB board and cable
Chapter 4. Removing a FRU or CRU 47
