Figure 10. Remove the storage drive cable and bracket
Screw specifications
Number of screws
M3 x L3 4
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement parts:
Storage drive
Storage drive cable
Storage drive bracket
Remove the battery pack
Remove the 2-cell battery pack (for models with storage drive)
Make sure the following FRUs (or CRUs) have been removed.
“Remove the lower case” on page 28
Step 1. Disconnect the cable from the system board.
Attention: Use your fingernail to pull the connector to unplug it. Do not pull the cable.
Step 2. Remove four screws and then remove the battery pack.
Chapter 4. Removing a FRU or CRU 33
