Attention: Do not pull the LCD bezel from the outer sides of the LCD bezel, otherwise the hooks
may be damaged. The lower side of the LCD bezel is fixed to the LCD panel with adhesive tape.
Detach with care.
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement part:
LCD bezel
Remove the stripe cover
Make sure the following FRUs (CRUs) have been removed.
“Remove the upper case ” on page 52
Step 1. Remove the stripe cover.
Figure 41. Remove the stripe cover
Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement part:
Stripe cover
Remove the hinge
Make sure the following FRUs (CRUs) have been removed.
“Remove the upper case ” on page 52
“Remove the LCD bezel” on page 54
“Remove the LCD panel” on page 57
Step 1. Remove ten screws and then carefully lift the LCD panel from the LCD module.
Chapter 4. Removing a FRU or CRU 55
