Figure 26. Remove one screw and the Wi-Fi card
Screw specifications Number of screws
M2 x L2.8 1
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement part:
Wi-Fi card
Remove the USB board
Make sure the following FRUs (or CRUs) have been removed.
“Remove the lower case” on page 32
Step 1. Disconnect the battery pack cable and the USB board cable from the system board.
Attention: Use your fingernail to pull the connector to unplug it. Do not pull the cable.
46
Lenovo V17 Gen 2 Hardware Maintenance Manual
