Remove the system fan
For ITL models
Make sure the following FRUs (or CRUs) have been removed.
“Remove the lower case” on page 32
Step 1. Disconnect the fan cable from the system board.
Attention: Use your fingernail to pull the connector to unplug it. Do not pull the cable.
Figure 23. Disconnect the fan cable
Step 2. Remove four screws and then remove the fan.
Figure 24. Remove four screws and the fan
44 Lenovo V17 Gen 2 Hardware Maintenance Manual
