“Remove the lower case” on page 32
Step 1. Disconnect the cable from the system board.
Attention: Use your fingernail to pull the connector to unplug it. Do not pull the cable.
Figure 15. Disconnect the cable
Step 2. Remove six screws and then remove the battery pack.
Figure 16. Remove the battery pack
Screw specifications
Number of screws
M2 x L3.5 6
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement part:
Chapter 4. Removing a FRU or CRU 39
