Figure 48. Remove the touchpad board cable
Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement parts:
Touchpad board cable
Remove the system board and the touchpad board cable
Make sure the following FRUs (or CRUs) have been removed.
“Remove the lower case” on page 48
“Remove the solid-state drive (SSD) module” on page 49
“Remove the solid-state drive (SSD) stand off” on page 50
“Remove the Wi-Fi card” on page 51
“Remove the heat sink” on page 52
Step 1. Remove two screws and then open the hinge.
Figure 49. Remove two screws and then open the hinge
Screw specifications
Number of screws
M2.5 x L5 2
56
Hardware Maintenance Manual
