Figure 41. Remove the Wi-Fi card
Screw specifications
Number of screws
M2 x L2.8 1
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
Wi-Fi card
Remove the heat sink
Make sure the following FRU (or CRU) has been removed.
“Remove the lower case” on page 48
Step 1. Disconnect the battery pack cable from the system board.
Attention: Use your fingernails to pull the connector to unplug it. Do not pull the cable.
Step 2. Loosen four screws and then remove the heat sink.
Figure 42. Remove the heat sink
Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
Heat sink
52
Hardware Maintenance Manual
