Figure 37. Remove one screw then remove the SSD by pulling it away from the slot
Screw specifications
Number of screws
M2 x L2.8 1
Step 3. Remove the SSD thermal pad.
Figure 38. Remove the SSD thermal pad
Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement parts:
SSD
SSD thermal pad
Remove the solid-state drive (SSD) stand off
Make sure the following FRU (or CRU) has been removed.
“Remove the lower case” on page 48
Step 1. Disconnect the battery pack cable from the system board.
Attention: Use your fingernails to pull the connector to unplug it. Do not pull the cable.
Step 2. Remove one screw then remove the SSD by pulling it away from the slot.
50
Hardware Maintenance Manual
