Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
Lower case
Remove the battery pack
Make sure the following FRUs (or CRUs) have been removed.
“Remove the lower case” on page 48
Step 1. Disconnect the battery pack cable from the system board. Remove two screws and then remove
the battery pack.
Attention: Use your fingernails to pull the connector to unplug it. Do not pull the cable.
Figure 36. Remove two screws and then remove the battery pack
Screw specifications Number of screws
M2 x L3.5 2
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
Battery pack
Remove the solid-state drive (SSD) module
Make sure the following FRU (or CRU) has been removed.
“Remove the lower case” on page 48
Step 1. Disconnect the battery pack cable from the system board.
Attention: Use your fingernails to pull the connector to unplug it. Do not pull the cable.
Step 2. Remove one screw then remove the SSD by pulling it away from the slot.
Chapter 4. Removing a FRU or CRU 49
