Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement parts:
EDP cable
Removable tapes
Remove the camera
Make sure the following FRUs (CRUs) have been removed.
“Remove the LCD module” on page 42
“Remove the LCD bezel” on page 44
“Remove the LCD panel” on page 45
“Remove the microphone rubbers” on page 46
Step 1. Disconnect the EDP cable from the camera board and then remove the camera.
Figure 33. Disconnect the EDP cable from the camera board and then remove the camera
Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement parts:
Camera
Removable tapes
Remove the LCD cover
Make sure the following FRUs (CRUs) have been removed.
“Remove the LCD module” on page 42
“Remove the LCD bezel” on page 44
“Remove the hinges” on page 44
“Remove the LCD panel” on page 45
“Remove the microphone rubbers” on page 46
“Remove the EDP cable” on page 46
“Remove the camera” on page 47
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
LCD cover
Chapter 4. Removing a FRU or CRU 47
