Remove the microphone rubbers
Make sure the following FRUs (CRUs) have been removed.
“Remove the LCD module” on page 42
“Remove the LCD bezel” on page 44
“Remove the LCD panel” on page 45
Step 1. Remove the microphone rubbers.
Figure 31. Remove the microphone rubbers
Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement parts:
Microphone rubbers
Removable tapes
Remove the EDP cable
Make sure the following FRUs (CRUs) have been removed.
“Remove the LCD module” on page 42
“Remove the LCD bezel” on page 44
“Remove the LCD panel” on page 45
Step 1. Disconnect the EDP cable from the camera board and then remove the EDP cable.
Figure 32. Disconnect the EDP cable from the camera board and then remove the EDP cable
46 Hardware Maintenance Manual
