Removal procedure for Lenovo V15 G3 IAP, Lenovo V15 G3 ABA, Lenovo
V15 G3 ABA 1, Lenovo V15 G3 ABA 2, and Lenovo V15 G3 ABA 3
Remove the lower case
Make sure the computer has been shut down before servicing the computer.
Step 1. Place the computer upside down on a flat surface.
Step 2. Remove eleven screws.
Figure 40. Remove eleven screws
Screw specifications Number of screws
M2 x L6
7
M2 x L4 4
Step 3. Pry up the latches and then remove the lower case.
Figure 41. Pry up the latches and remove the lower case
54 Hardware Maintenance Manual
