Screw specifications Number of screws
M2 x L2 6
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
Hinges
Remove the LCD panel
Make sure the following FRUs (CRUs) have been removed.
“Remove the LCD module” on page 47
“Remove the LCD bezel” on page 49
Step 1. Remove the two pieces of removable tape with tweezers.
Note: The removable tape is not reusable. Replace it when replacing related FRUs.
Figure 35. Remove the two pieces of removable tape with tweezers
Step 2. Lift the LCD panel and then disconnect the EDP cable from the LCD panel.
50
Hardware Maintenance Manual
