Screw specifications Number of screws
M2.5 x L5 2
Step 2. Disconnect the touchpad board cable from the touchpad and disconnect cables connected to the
system board.
Figure 28. Disconnect the touchpad board cable and disconnect cables connected to the system board
Step 3. Remove four screws and then remove the system board with touchpad board cable.
Figure 29. Remove four screws and then remove the system board with touchpad board cable
Screw specifications Number of screws
M2 x L2.8 3
M2 x L3.5 1
Step 4. Disconnect the touchpad board cable from the system board.
46
Hardware Maintenance Manual
