Figure 15. Remove the SSD thermal pad
Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement parts:
SSD bracket
SSD
SSD thermal pad
Remove the Wi-Fi card
Make sure the following FRU (or CRU) has been removed.
“Remove the lower case” on page 34
Step 1. Disconnect the battery pack cable from the system board.
Attention: Use your fingernails to pull the connector to unplug it. Do not pull the cable.
Step 2. Detach the main and auxiliary antenna cable connectors. Remove one screw and then remove the
Wi-Fi card by pulling it away from the slot.
Figure 16. Remove the Wi-Fi card
Screw specifications
Number of screws
M2 x L2.8 1
Chapter 4. Removing a FRU or CRU 39
