Screw specifications Number of screws
M2 x L6 6
M2 x L4 4
Step 3. Pry up the latches and then remove the lower case.
Figure 6. Pry up the latches and remove the lower case
Go to https://support.lenovo.com/partslookup to look up the Lenovo part number of the following replacement
part:
Lower case
Remove the hard disk drive (HDD) module
Make sure the following FRU (or CRU) has been removed.
“Remove the lower case” on page 34
Step 1. Disconnect the battery pack cable from the system board.
Attention: Use your fingernails to pull the connector to unplug it. Do not pull the cable.
Figure 7. Disconnect the battery pack cable from the system board
Step 2. Disconnect the HDD cable from the system board. Remove four screws and then remove the HDD
module.
Chapter 4. Removing a FRU or CRU 35
